System Overview

Core Thesis

Systems with meaningful cyclic observables and defensible coupling assumptions can sometimes be modelled with Kuramoto-family phase dynamics. The orchestrator provides a shared workflow: extract phases, integrate a declared coupling model, measure coherence, and produce bounded control proposals. Reusing the equations across domains does not make their semantics or evidence interchangeable; each binding still needs domain-specific calibration and validation.

The binding spec carries the reusable model contract—signals, topology, coupling, and objectives—while domain-specific data preparation, calibration, acceptance thresholds, and deployment evidence remain outside that abstraction.

Pipeline

For a step-by-step map from YAML to extractors, engines, supervisor, actuation, audit, and replay, see How the Pipeline Fires.

Domain Signals
    |
    v
Domain Binder -----> BindingSpec (YAML)
    |                   declares oscillators, layers, coupling, objectives
    v
Oscillator Extractors
    |  P: Hilbert phase from continuous waveform
    |  I: inter-event frequency from timestamps
    |  S: ring-phase from discrete state sequence
    v
UPDEEngine
    |  dtheta_i/dt = omega_i
    |              + sum_j K_ij sin(theta_j - theta_i - alpha_ij)
    |              + zeta sin(Psi - theta_i)
    |
    |  Methods: Euler (default), RK4, RK45 (adaptive Dormand-Prince)
    |  Output: phases, R per layer, cross-layer alignment
    v
ImprintModel (optional)
    |  m_k(t+dt) = m_k(t)*exp(-decay*dt) + exposure*dt
    |  Modulates: Knm scaling, alpha lag offset
    |  Captures slow accumulation (drug PK, fatigue, tool wear)
    v
Monitor Layer
    |  CoherenceMonitor: R, PLV, layer coherence
    |  BoundaryObserver: hard/soft limit checks
    |  LyapunovGuard: chaos detection
    |  ChimeraDetector: partial sync patterns
    |  WindingTracker: cumulative rotation counts
    |  PAC: phase-amplitude coupling
    |  TransferEntropy: directed information flow
    |  Recurrence/RQA: dynamical complexity
    |  EVS: eigenvalue stability
    |  Poincare: section analysis
    v
Supervisor (RegimeManager + SupervisorPolicy + PolicyEngine)
    |  RegimeManager: R thresholds + hysteresis -> regime transitions
    |  SupervisorPolicy: default regime-driven actions
    |  PolicyEngine: YAML-declared domain-specific rules (policy.yaml)
    |  ActiveInferenceAgent: FEP-based zeta/Psi proposal generation
    |  PredictiveSupervisor: model-based candidate action generation
    |  PetriNet: protocol sequencing FSM
    |  Decides: ControlActions on {K, alpha, zeta, Psi}
    |  Regime: NOMINAL / DEGRADED / CRITICAL / RECOVERY
    v
ActuationMapper + ActionProjector
    |  Maps ControlActions to domain-specific actuator commands
    |  Clips values, enforces rate limits
    |  Validates against boundary constraints
    v
Domain Actuators (external)

Pipeline Execution Flow

Each integration step follows this sequence:

1. Extract: oscillator extractors produce PhaseState from raw signals (P/I/S channels).
2. Quality gate: PhaseQualityScorer computes a finite-pair, amplitude-weighted confidence score and masks unreliable oscillators. Weight normalisation before summation prevents large finite amplitudes from producing a false zero-confidence report. The caller applies mask weights to the coupling matrix before integration.
3. Imprint (if enabled): update memory vector, modulate K and alpha.
4. Integrate: UPDEEngine.step() advances phases by one dt.
5. Monitor: compute R, PLV, check boundaries, update Lyapunov estimates, detect chimeras.
6. Supervise: evaluate regime, decide control actions.
7. Actuate: map actions to domain commands, apply rate limits.
8. Audit: log step to JSONL trace.

A historical local snapshot measured the UPDE step at about 0.1 ms for N=64 on one pure-Python configuration (2026-04-04, i5-11600K). Full-pipeline latency depends on enabled extractors, monitors, audit work, backend, and host. This measurement is regression context only; it does not establish a sampling-rate or control-loop deadline.

Dual Objective: R_good / R_bad

The ObjectivePartition divides layers into two groups:

• R_good (good_layers): coherence to maximise. High R_good means healthy synchronisation — coordinated neural rhythms, stable power grid frequency, efficient service orchestration.
• R_bad (bad_layers): coherence to suppress. High R_bad means pathological lock-in — epileptic seizures, retry storms, cascading failures, market flash crashes.

The supervisor seeks to raise R_good while lowering R_bad. This dual objective captures systems where some synchrony is desirable and some is harmful. The partition is declared in the binding spec:

objectives:
  good_layers: [0, 1, 2, 3]
  bad_layers: [4, 5]
  R_good_target: 0.8
  R_bad_ceiling: 0.3

Domain-Agnostic Architecture

The engine has no domain knowledge. All domain semantics live in the BindingSpec:

• Which signals are oscillators (P/I/S channel).
• How oscillators group into hierarchy layers.
• What coupling template to use.
• Which boundaries constitute violations.
• What actuators exist and their limits.
• What regime thresholds apply.

A new domain requires writing a binding spec and (optionally) custom extractors. No engine code changes. The system ships with 36 domainpacks covering neuroscience, power grids, finance, robotics, traffic, industrial control, and more.

Engine Variants

Engine	Equation	Use case
UPDEEngine	Standard Kuramoto	General-purpose, dense coupling
SparseUPDEEngine	Standard Kuramoto, CSR sparse	Sparse topology, O(N + E) storage and derivative work
SheafUPDEEngine	Vector-valued phases	Multi-dimensional oscillators
StuartLandauEngine	Phase + amplitude	Systems with amplitude dynamics
InertialKuramotoEngine	Second-order (with inertia)	Power grids, mechanical systems
SimplicialEngine	3-body coupling	Higher-order interactions
HypergraphEngine	Hyperedge coupling	Group interactions
TorusEngine	Torus topology	Geometric constraints
SwarmalatorEngine	Position + phase	Swarm robotics
DelayedEngine	Time-delayed coupling	Signal propagation delays
SplittingEngine	Operator splitting	Stiff multi-scale systems
JaxUPDEEngine	JIT Kuramoto with validated host readback	Configured JAX CPU/GPU/TPU device

Engine variants expose step() / run() with model-specific state shapes and controls. SheafUPDEEngine returns independent (N, D) phase arrays; consumers construct any UPDEState diagnostics they require. Its adaptive solver advances one complete configured interval per step. See the cellular-sheaf contract.

Successful scalar dense/CSR Kuramoto steps publish canonical phases in their actual precision: rounded upper remainders and signed zero become positive zero, interior values remain, and nonfinite computed output refuses. A refused step retains caller phases and the adaptive proposal for valid same-instance retry. JAX Kuramoto uses its configured float32/float64 period; device-array autodiff is provided by the pure functional API away from wrap cuts. The generated browser WebGPU UPDE package implements float32 Euler with real control/readback guards; a software adapter diagnostic does not establish hardware performance.

Key Data Structures

Structure	Module	Purpose
BindingSpec	binding.types	Domain declaration (YAML)
PhaseState	oscillators.base	Extracted phase per oscillator
CouplingState	coupling.knm	Knm + alpha + active template
UPDEState	upde.metrics	R per layer, cross-layer alignment
BoundaryState	monitor.boundaries	Violations (soft/hard)
ControlAction	actuation.mapper	Knob adjustment command
ImprintState	imprint.state	Memory imprint vector
PolicyRule	supervisor.policy_rules	Condition-action rule
PolicyEngine	supervisor.policy_rules	Rule evaluator
PetriNet	supervisor.petri_net	Protocol FSM
RegimeEvent	supervisor.events	Event bus message
SPOError	exceptions	Exception hierarchy

Rust FFI Acceleration

Performance-critical components have Rust implementations in spo-kernel/:

Crate	Contents
spo-engine	UPDE steppers, coupling, order params, PAC, plasticity, winding
spo-oscillators	P/I/S extractors, quality scorer
spo-supervisor	Boundary observer, coherence monitor, regime manager, policy
spo-types	Shared types, config, errors
spo-ffi	PyO3 bindings for the supported native surface
spo-wasm	WebAssembly build for browser

The FPGA Verilog core is a separate research artefact, not a Rust workspace crate and not a validated deployment target.

The Python code auto-detects spo_kernel availability and uses the Rust path when present. Fallback to pure Python is always available. Rust-Python parity is verified by tests/test_ffi_parity.py.

Audit and Replay

Every step writes a JSONL record:

{"t": 0.01, "step": 1, "regime": "nominal", "R": [0.82, 0.75],
 "actions": [], "boundary_violations": []}

Deterministic replay from audit logs verifies reproducibility:

from scpn_phase_orchestrator.runtime.replay import ReplayEngine

replay = ReplayEngine("audit_trace.jsonl")
entries = replay.load()
header = replay.load_header(entries)
if header is not None:
    engine = replay.build_engine(header)
    replay.verify_determinism_chained(engine, entries)

The AuditLogger supports structured queries for post-hoc analysis of regime transitions, control actions, and boundary events.

Deployment Options

Target	Method	Latency
Python process	pip install	historical local ~0.1 ms/step at N=64; remeasure
Rust FFI	python tools/install_spo_kernel.py --release	measure on the deployment target
Docker	docker compose up	not yet measured
FPGA research artefact	Verilog core and compiler output	no synthesis, WCET, or hardware validation yet
Browser	WASM bundle	not yet measured
gRPC service surface	runtime.server_grpc.PhaseStreamServicer	integration-owned server startup; not measured

Stochastic Synthesis of Geometric Fields (SSGF)

The SSGF subsystem extends the phase orchestrator with geometric field theory concepts from the SCPN framework:

• GeometryCarrier: tracks the state of a geometric field coupled to the oscillator phases. Phase coherence modulates field curvature.
• Topological Integration Observable (p_h1): monitors the system's thermodynamic consistency — entropy production, free energy balance, Boltzmann weighting of states.
• PGBO (Probabilistic-Geometric Boundary Observer): monitors geometric constraints — closure, consistency of curvature with coupling topology.
• Ethical Cost: computes a configurable optimisation penalty named “ethical cost”; it is not an ethical assessment, certification, or authority for medical, nuclear, or other safety-critical actuation.

SSGF is an optional research construction. Enable it only for simulation or review where its cost terms and coupling decoder are explicitly part of the experiment. The implementation does not establish physical validity for plasma, gravitational, cosmological, clinical, or other target domains.

Testing and Validation

The repository maintains module-owned unit, integration, property, performance, native-parity, and physics-validation tests. The generated capability inventory reports the current test-file count; CI collection is the authority for the executable test count.

Tier	Scope
Unit tests	Individual functions and classes
Integration tests	Cross-module pipelines
Property tests	Hypothesis-based invariant verification
Performance benchmarks	Local regression thresholds and snapshots
Rust parity tests	Python versus Rust output equivalence
Physics validation	Mathematical and reference-case acceptance

CI runs the main suite on every push across supported Python 3.11–3.13. Rust and FFI lanes cover the platform matrix declared in the versioned distributed inventory at tools/ci_workflow_policy.json.

What This System Is NOT

• Not a general ODE solver. It solves specifically the Kuramoto family of coupled oscillator equations. For arbitrary ODEs, use scipy.integrate or diffrax.
• Not a signal processing library. Phase extraction is the entry point, not the focus. For signal processing, use MNE-Python, scipy, or librosa.
• Not a replacement for domain expertise. The binding spec encodes domain knowledge. The engine is only as good as the spec.
• Not real-time guaranteed. No Python, Rust, FPGA, or network path in this repository has a published worst-case execution-time and target-hardware evidence package. Qualify the complete deployment independently.

Version History

Version	Milestone
v0.1	Core UPDE engine, P/I/S extractors, basic supervisor
v0.2	Sparse engine, RK45 adaptive stepping, PLV/PAC monitors
v0.3	Petri net supervisor, event bus, boundary observer, Rust FFI
v0.4	Stuart-Landau amplitude dynamics, imprint model, 24 domainpacks
v0.4.1	Sheaf UPDE, active inference controller, SSGF, Hodge decomposition
v1.0.0	First stable public baseline with guarded docs, packaging, and release metadata
v1.1.0	Hardened backend boundaries, expanded runtime and research capabilities, and evidence-bounded public documentation

The package metadata and documentation homepage name the current release. See the public roadmap for remaining evidence and productisation work instead of treating historical 0.x milestones as current scope.

Further Reading

• Oscillators P/I/S — channel extraction details.
• Control Knobs — K, alpha, zeta, Psi.
• Memory Imprint — adaptation model.
• Phase Contract — interface specification.
• Knm Calibration — coupling tuning.
• Start Here — role-based entry points.

References

• [kuramoto1975] Y. Kuramoto (1975). Self-entrainment of a population of coupled non-linear oscillators. Lecture Notes in Physics 39, 420-422.
• [acebron2005] J. A. Acebron et al. (2005). The Kuramoto model: a simple paradigm for synchronization phenomena. Rev. Mod. Phys. 77, 137-185.
• [sakaguchi1986] H. Sakaguchi & Y. Kuramoto (1986). A soluble active rotater model. Prog. Theor. Phys. 76, 576-581.
• [friston2010] K. J. Friston (2010). The free-energy principle. Nature Rev. Neuroscience 11, 127-138.
• [strogatz2000] S. H. Strogatz (2000). From Kuramoto to Crawford. Physica D 143, 1-20.
